16. MITSUBISHI ELECTRIC PLC 16-1
16. MITSUBISHI ELECTRIC PLC
Available PLCs
A Series Link, QnA Series Link, QnH (Q) Series Link, A Link + Net10
*1
*1 For more information on A link + Net10, refer to page 16-13.
*2 For notes on the connection between the tool port of a Q00/Q01 CPU and the V7 series using the serial
communication function, refer to page 16-3.
For the description of the ladder transfer function, refer to page 16-15.
*3 For connection to MJ2 of a V706, use an MJ2-PLC adaptor plus QCPU2.
Select PLC Type CPU Unit/Port Connection PLC2Way
A series link
A2A, A3A
AJ71C24-S6
AJ71C24-S8
AJ71UC24
RS-232C [Wiring Diagram 2]
A2U, A3U, A4U AJ71UC24
A1, A2, A3
A1N, A2N, A3N
A3H, A3M, A73
AJ71C24
AJ71C24-S3
AJ71C24-S6
AJ71C24-S8
AJ71UC24
RS-422 [Wiring Diagram 5]
A0J2, A0J2H A0J2C214-S1
A2US
A1SJ71UC24-R2 RS-232C [Wiring Diagram 1]
A1SJ71UC24-R4 RS-422 [Wiring Diagram 5]
A1SJ71UC24-PRF RS-232C [Wiring Diagram 1]
A1S, A1SJ, A2S
A1SJ71C24-R2 RS-232C [Wiring Diagram 1]
A1SJ71C24-R4 RS-422 [Wiring Diagram 5]
A1SJ71C24-PRF RS-232C [Wiring Diagram 1]
A2CCPUC24 CPU built-in link port RS-232C [Wiring Diagram 1]
QnH (A mode)
A1SJ71UC24-R2 RS-232C [Wiring Diagram 1]
A1SJ71UC24-R4 RS-422 [Wiring Diagram 5]
QnA series link
Q2A, Q3A, Q4A
Q2ASx
AJ71QC24N
RS-232C [Wiring Diagram 2]
RS-422 [Wiring Diagram 5]
AJ71QC24
RS-232C [Wiring Diagram 2]
RS-422 [Wiring Diagram 5]
A1SJ71QC24
RS-232C [Wiring Diagram 1]
RS-422 [Wiring Diagram 5]
AJ71QC24-R4(CH1) RS-422 [Wiring Diagram 6]
AJ71QC24-R4(CH2) RS-422 [Wiring Diagram 5]
QnH (Q) series link
QnH (Q mode)
QJ71C24
RS-232C [Wiring Diagram 1]
Q00, Q01, Q00J RS-422 [Wiring Diagram 5]
Q00, Q01
Tool port
*2
RS-232C
Hakko Electronics’ cable
“QCPU2”
*3
A link + Net10
Standard type link +unit for A series link
*1
