18. MOELLER PLC
Available PLCs
Communication Setting
The recommended communication parameter settings of the PLC and the V7 series are as follows:
Available Memory
The available memory setting range varies depending on the PLC model. Be sure to set within the
range available with the PLC to be used. Use [TYPE] when assigning the indirect memory for macro
programs.
Select PLC Type PLC Connection
PS4 PS4-201-MM1 (PRG port)
RS-232C [Wiring Diagram 1]
+
ZB4-303-KB1 Cable made by
MOELLER
Item Setting on PLC V7 Comm. Parameter Setting
Baud rate 9600 bps 9600 bps
Port 1 1
Parity Not provided Not provided
Transmission
code
Data length 8 8
Stop bit 1 1
Memory TYPE Remarks
M (marker) 0 MW as word device
