Appendix 1 PLC2Way App1-19
Notes on Screen Data Transfer
Temperature Control/PLC2 Program
When using the temperature control network/PLC2Way communications, it is necessary to transfer the
temperature control/PLC2 program to the V7 series.
When the temperature control network/PLC2Way setting has been made, the program is automatically
transferred to the V7 series together with screen data.
When [ Temp./PLC2] is selected in the [Transfer] dialog, only the temperature control/PLC2
program can be transferred to the V7 series.
When the Main Menu screen is displayed after transferring screen data, the [Extension] switch
appears.
If the [Extension] switch does not appear, transfer font data.
Pressing the switch brings up the “Extension Program Info.” screen where the temperature
control/PLC2Way driver setting and temperature control network/PLC2way setting can be reviewed.
For details, refer to “Chapter 6, MONITOUCH Operations” in the separate Hardware Specifications for
the V7 series or V706.
