13. KOYO ELECTRONICS PLC 13-1
13. KOYO ELECTRONICS PLC
Available PLCs
*1 When connecting to MJ2 on the V706, use an MJ2-PLC adaptor plus the designated cables.
Select PLC Type PLC Unit/Port Connection
SU/SG
SU-5/5E/6B/5M/6M U01-DM
RS-232C [Wiring Diagram 1]
RS-422 [Wiring Diagram 3]
SU-5E/6E
Universal port 1 on CPU
RS-232C [Wiring Diagram 1]
RS-422 [Wiring Diagram 7]
SU-5M/6M
Universal port 3 on CPU
RS-485 [Wiring Diagram 8]
Universal port 2 on CPU
RS-232C
*1
KOYO’s programmer
connecting cable S-30JG-E
+
KOYO’s conversion
connector cable S-15CNJ
SZ-4
PORT2 on CPU
(universal communication port)
SZ-4M
PORT2 on CPU
(universal communication port)
RS-232C
*1
KOYO’s programmer
connecting cable S-30JG-E
+
KOYO’s conversion
connector cable S-15CNJ
+
KOYO’s conversion
connector S-15HCNP1
SG-8
G01-DM
RS-232C [Wiring Diagram 1]
RS-422 [Wiring Diagram 4]
Port on CPU
RS-232C [Wiring Diagram 1]
RS-422 [Wiring Diagram 4]
PZ3
Universal communication port on the CPU
unit
RS-232C [Wiring Diagram 2]
RS-485 [Wiring Diagram 6]
SR-T SR-6T (Toyota version)
U01-DM
RS-232C [Wiring Diagram 1]
RS-422 [Wiring Diagram 3]
G01-DM
RS-232C [Wiring Diagram 1]
RS-422 [Wiring Diagram 4]
SR-T (K Protocol) SR-1T (Toyota version) Terminal block on the CPU unit RS-422 [Wiring Diagram 5]
SU/SG
(K-Sequence)
SU-5E/6B
Universal port 1 on CPU
RS-232C [Wiring Diagram 1]
RS-485 [Wiring Diagram 7]
SU-5M/6M
Programmer port on CPU
RS-232C
*1
KOYO’s programmer
connecting cable S-30JG-E
Universal port 3 on CPU RS-485 [Wiring Diagram 8]
Universal port 2 on CPU
RS-232C
*1
KOYO’s programmer
connecting cable S-30JG-E
+
KOYO’s conversion
connector cable S-15CNJ
SZ-4
PORT1 on CPU (programmer port)
PORT2 on CPU
(universal communication port)
SZ-4M
PORT1 on CPU (programmer port)
PORT2 on CPU
(universal communication port)
RS-232C
*1
KOYO’s programmer
connecting cable S-30JG-E
+
KOYO’s conversion
connector cable S-15CNJ
+
KOYO’s conversion
connector S-15HCNP1
