5. DELTA PLC 5-1
5. DELTA PLC
Available PLCs
Communication Setting
The recommended communication parameter settings of the PLC and the V7 series are as follows:
Available Memory
The available memory setting range varies depending on the PLC model. Be sure to set within the
range available with the PLC to be used. Use [TYPE] when assigning the indirect memory for macro
programs.
Select PLC Type PLC Unit/Port Connection
DVP series DVP series RS-485 Communication port RS-485 [Wiring Diagram 1]
Item Setting on PLC V7 Comm. Parameter Setting
Baud rate 9600 bps 9600 bps
Port 1 1
Parity Even Even
Transmission
code
Data length 7 7
Stop bit 1 1
Memory TYPE Remarks
D (data register) 0
X (input relay) 1
Y (output relay) 2
M (auxiliary relay) 3
S4
T (timer) 5
C (counter) 6
32C (high-speed counter) 7
To Next Page
