Hakko Electronics V Series User Manual

9. GE Fanuc PLC 9-1
9. GE Fanuc PLC
Available PLCs
Communication Setting
The recommended communication parameter settings of the PLC and the V7 series are as follows:
90 Series
90 Series SNP-X
Select PLC Type PLC Unit/Port Connection
90 series Series 90-30 Programmable coprocessor (PCM)
RS-232C [Wiring Diagram 1]
RS-485 [Wiring Diagram 2]
90 series (SNP-X)
Series 90 micro
Series 90-30
CPU port RS-485 [Wiring Diagram 3]
Item Setting on PLC V7 Comm. Parameter Setting
Baud rate 19200 bps 19200 bps
Port 01 (“0” for ×10, “1” ×1) 0
Parity Odd Odd
Transmission
code
Data length 8 8
Stop bit 1 1
Functions Host link function (fixed) −
Response delay time 0 (fixed) −
Timeout None (fixed) −
ASCII/HEX HEX (fixed) −
Item Setting on PLC V7 Comm. Parameter Setting
Baud rate 19200 bps 19200 bps
Parity Odd Odd
Transmission
code
Data length 8 8
Stop bit 1 1
Functions SNP-X (fixed) −
