2. Allen-Bradley PLC 2-3
SLC500 Series, Micro Logix 1000
PLC-5 Series: Switch Setting
1785-KE
SW1 (Protocol)
SW2 (Station number)
Set the station number of 1785-KE. (This station should not be duplicated in the network.)
Memory TYPE Remarks
N (integer) 0
B (bit) 1
T.ACC (timer/current value) 2
T.PRE (timer/set value) 3
C.ACC (counter/current value) 4
C.PRE (counter/set value) 5
I (input) 6
O (output) 7
S (status) 8
T (timer/control) 9
C (counter/control) 10
R (control) 11
R.LEN (control/data length) 12
R.POS (control/data position) 13
D (BCD) 14
A (ASCII) 15
F (FLOAT) 16
ST (STRING) 17
No Setting Contents
1ON
BCC, even, no2OFF
3OFF
4 ON Duplicated message unacceptable
5 OFF Handshaking signal ignored
6 ON Execution of diagnosis command
No Setting Contents
1ON
1st digit (octal)
2ON
3 ON/OFF
2nd digit (octal)4 ON/OFF
5 ON/OFF
6 ON/OFF
3rd digit (octal)7 ON/OFF
8 ON/OFF
