15. Matsushita Electric Works PLC 15-1
15. Matsushita Electric Works PLC
Available PLCs
*1 For connection to MJ2 of a V706, use an MJ2-PLC adaptor plus AFC8513.
Communication Setting
The recommended communication parameter settings of the PLC and the V7 series are as follows:
* If a tool port (the ladder port for RS-232C) is used, the range of PLC parameter setting is limited as
below. Adjust the PLC parameter setting to communication parameter setting of the V7 series.
• Baud rate: 9600, 19200bps (maximum 115 kbps available with FP2)
• Parity: Odd (fixed)
• Data bit: 8 or 7 (select “8” normally)
• Stop bit: 1 (fixed)
Select PLC Type PLC Unit/Port Connection PLC2Way
MEWNET
FP1 RS-232C port on the CPU unit
RS-232C [Wiring Diagram 1]
FP3
AFP3462
RS-232C [Wiring Diagram 1]
AFP3463
RS-422 [Wiring Diagram 4]
FP5 AFP5462
RS-232C [Wiring Diagram 1]
FP10
RS-232C tool port on the CPU unit
RS-232C [Wiring Diagram 1]
AFP5462
RS-232C [Wiring Diagram 1]
FP10S
RS-232C port on the CPU unit
RS-232C [Wiring Diagram 1]
AFP3462
RS-232C [Wiring Diagram 1]
AFP3463
RS-422 [Wiring Diagram 4]
FP0
RS-232C tool port on the CPU unit
MATSUSHITA’s RS-232C
cable “AFC8513”
*1
RS-232C port on the CPU unit
RS-232C [Wiring Diagram 3]
FP2
RS-232C port on the CPU unit
MATSUSHITA’s RS-232C
cable “AFC8513”
*1
RS-232C port on the CPU unit
RS-232C [Wiring Diagram 2]
Item Setting on PLC V7 Comm. Parameter Setting
Baud rate 19200 bps 19200 bps
Port [0] × 10, [1] × 11
Parity Even Even
Transmission
code
Data bit 7 (ASCII) 7
Stop bit 1 1
Transmission mode Computer link function (fixed) −
Control signal Invalid (fixed) −
