12. KEYENCE PLC 12-3
KV-700 CPU
*1 Maximum baud rate available is 57600 bps. Select the appropriate baud rate depending on the used PLC and
environment.
KZ24/300 CPU
*1 Maximum baud rate available is 38400 bps. If a higher baud rate is selected, communications are performed
at 9600 bps.
KV10/24 CPU
*1 Maximum baud rate available is 57600 bps. If a higher baud rate is selected, communications are performed
at 9600 bps.
Item Setting on PLC V7 Comm. Parameter Setting
Port 0 0
Baud rate
*1
9600 bps 9600 bps
Parity Even −
Transmission
code
Data length 8 −
Stop bit 1 −
Item Setting on PLC V7 Comm. Parameter Setting
Port 0 0
Baud rate 38400 bps
38400 bps
*1
Parity Even −
Transmission
code
Data length 8 −
Stop bit 1 −
Item Setting on PLC V7 Comm. Parameter Setting
Port 0 0
Baud rate 57600 bps
57600 bps
*1
Parity Even −
Transmission
code
Data length 8 −
Stop bit 1 −
