16-10 16. MITSUBISHI ELECTRIC PLC
Wiring Diagram 4
RS-422
Wiring Diagram 5
PLC
SD
RD
SG
2
3
7
1
2
3
4
5
7
SD
RD
RS
CS
SG
SHELL
8
7
5
*1
D-sub 25-pin (male)
* Use shielded twist-pair cables.
D-sub 25-pin (male)RJ-45 8-pin
V Series
CN1
V706
MJ2
*1 Pin No. 1 of CN1 is used
as FG.
The metal shell of the
modular jack 2 on the
V706 is used as SG.
Signal
Name
Pin No. Pin No.
Signal
Name
Pin No.
PLC
SDA
SDB
SG
RDB
RDA
1
7
12
13
24
25
SG
+SD
-SD
+RD
-RD
5
1
2
7
8
SHELL
*1
* Use shielded twist-pair cables.
D-sub 25-pin (male)RJ-45 8-pin
V Series
CN1
V706
MJ2
*1 Pin No. 1 of CN1 is used
as FG.
The metal shell of the
modular jack 2 on the
V706 is used as SG.
Signal
Name
Pin No. Pin No.
Signal
Name
