App5-10 Appendix 5 Ethernet
Transferring Screen Data from V-SFT Editor
1. Click the [Transfer] icon. The [Transfer] dialog is displayed.
2. Attach a check mark ( ) to [ Transfer through
Ethernet].
3. Click the [Detail Setting] button. The [IP Address Setting]
dialog is displayed.
4. Enter the IP address of the V7 series to which the
screen data is to be transferred.
When a list is shown, select the IP address of the
V7 series, and click the [<<] button. The host name
and the IP address are automatically entered.
Click [OK].
