Appendix 6 Universal Serial Communications App6-45
System Memory ($s)
System memory is memory that writes V series action status when the V Series is currently displaying
something.
With this written information, it is possible to check overlap status, buffer area, printer, backlight, and
slave station status in multi-drop connection mode.
* System memory cannot be read or written from the host computer.
In the table below, a small part ($s80 to 95) of system memory is extracted. For more information on
other areas of system memory, refer to Appendix 1 in the Reference Manual (Function).
Address Contents
:
79
80 Universal serial port switch output 0 Output code 0 - 15
81 Universal serial port switch output 1 Output code 16 - 31
82 Universal serial port switch output 2 Output code 32 - 47
83 Universal serial port switch output 3 Output code 48 - 63
84 Universal serial port switch output 4 Output code 64 - 79
85 Universal serial port switch output 5 Output code 80 - 95
86 Universal serial port switch output 6 Output code 96 - 111
87 Universal serial port switch output 7 Output code 112 - 127
88 Universal serial port switch output 8 Output code 128 - 143
89 Universal serial port switch output 9 Output code 144 - 159
90 Universal serial port switch output 10 Output code 160 - 175
91 Universal serial port switch output 11 Output code 176 - 191
92 Universal serial port switch output 12 Output code 192 - 203
93 Universal serial port switch output 13 Output code 208 - 223
94 Universal serial port switch output 14 Output code 224 - 239
95 Universal serial port switch output 15 Output code 240 - 255
96
97
:
