13. KOYO ELECTRONICS PLC 13-3
Switch Setting
U-01DM
On-line/Off-line switch: On-line
UNIT ADR switch: “0” for ×10, “1” for ×1
SW4 DIP switch:
SW5 DIP switch:
No Setting Contents
1ON
Same as that set on V7
Normally 19200 bps
2ON
3ON
4 ON With parity
5 OFF Self-diagnosis
6OFF
Response delay time
0 msec
7OFF
8OFF
No Setting Contents
1 OFF Master/slave control
2 OFF Slave
3 OFF Communication timeout
4 OFF HEX mode
