14-2 14. LG PLC
MASTER-KxxxS CNET / GLOFA CNET / GM Series CPU
Available Memory
The available memory setting range varies depending on the PLC model. Be sure to set within the
range available with the PLC to be used. Use [TYPE] when assigning the indirect memory for macro
programs.
MASTER-K10/60/200
MASTER-K500/1000
Item Setting on PLC V7 Comm. Parameter Setting
Baud rate 38400 bps 38400 bps
Parity Not provided Not provided
Transmission
code
Data length 8 8
Stop bit 1 1
Memory TYPE Remarks
D (data register) 0
M (auxiliary relay) 1
P (input/output relay) 2 Input: Read only
K (keep relay) 3
TC (timer/current value) 4
CC (counter/current value) 5
TS (timer/set value) 6
CS (counter/set value) 7
Memory TYPE Remarks
P (input/output relay) 0 Input: Read only
M (relay) 1
L (link relay) 2
K (keep relay) 3
F (special relay) 4 Read only
T (timer/current value) 5
C (counter/set value) 6
D (data register) 7
To Next Page
