Transducer connection
QuantumX A03031_24_E00_01 HBM: public 139
Thermocouple material 2 (-)Thermocouple material 1 (+)Type
T Copper Copper-nickel
S Rhodium-platinum (10%) Platinum
I Nickel-chrome Copper-nickel
B Rhodium-platinum (30%) Rhodium-platinum (6%)
N Nickel-chrome-silicone
1)
Nickel-silicone
R Rhodium-platinum (13%) Platinum
1)
Nicrosil
When recording temperatures with thermocouples with amplifiers MX840B or
MX440B, you must solder the "1-THERMO-MX BOARD" board into the connector
plug.
Position of board in plug
1
5
106
PT1000
PINs to be soldered
S Insert the 1-THERMO-MX BOARD in the correct position between the plug
pins
Notice
Check the position with the plug shape (see picture above).
In this position, the PT1000 of the cold spot compensation element is on top.
