318 Programming: Q Parameters
9.8 Additional Functions
10 - Feed rate for milling in active fixed cycle
11 - Direction of rotation for active fixed cycle
12 - Dwell time for active fixed cycle
13 - Thread pitch for Cycles 17, 18
14 - Milling allowance for active fixed cycle
15 - Direction angle for rough out in active fixed cycle
Data from the tool table, 50 1 Tool no. Tool length
2 Tool no. Tool radius
3 Tool no. Tool radius R2
4 Tool no. Oversize for tool length DL
5 Tool no. Oversize for tool radius DR
6 Tool no. Oversize for tool radius DR2
7 Tool no. Tool inhibited (0 or 1)
8 Tool no. Number of the replacement tool
9 Tool no. Maximum tool age TIME1
10 Tool no. Maximum tool age TIME2
11 Tool no. Current tool age CUR. TIME
12 Tool no. PLC status
13 Tool no. Maximum tooth length LCUTS
14 Tool no. Maximum plunge angle ANGLE
15 Tool no. TT: Number of tool teeth CUT
16 Tool no. TT: Wear tolerance for length LTOL
17 Tool no. TT: Wear tolerance for radius RTOL
18 Tool no. TT: Rotational direction DIRECT (0=positive/–
1=negative)
19 Tool no. TT: Offset in plane R-OFFS
20 Tool no. TT: Offset for length L-OFFS
21 Tool no. TT: Break tolerance for length LBREAK
22 Tool no. TT: Break tolerance for RBREAK radius
23 Tool no. PLC value
Group name, ID no. Number Index Meaning
