HEIDENHAIN iTNC 530 319
9.8 Additional Functions
24 Tool no. TS: Center misalignment in reference axis
25 Tool no. TS: Center misalignment in minor axis
26 Tool no. TS: Spindle angle for calibration
27 Tool no. Tool type for the pocket table
28 Tool no. Maximum speed
No index: Data of the currently active tool
Pocket table data, 51 1 Pocket number Tool number
2 Pocket number Special tool: 0=no, 1=yes
3 Pocket number Fixed pocket: 0=no, 1=yes
4 Pocket number Locked pocket: 0=no, 1=yes
5 Pocket number PLC status
6 Pocket number Tool type
7 to 11 Pocket number Value from column P1 to P5
12 Pocket number Pocket reserved: 0=no, 1=yes
13 Pocket number Box magazine: Pocket above locked (0=no, 1=yes)
14 Pocket number Box magazine: Pocket below locked (0=no, 1=yes)
15 Pocket number Box magazine: Pocket to the left locked (0=no, 1=yes)
16 Pocket number Box magazine: Pocket to the right locked (0=no,
1=yes)
Tool pocket, 52 1 Tool no. Pocket number P
2 Tool no. Tool magazine number
File information, 56 1 - Number of lines in the tool table TOOL.T
2 - Number of lines in the active datum table
3 Q parameter
number, as of
which the status
of the axes is
stored. +1: axis
active, -1: axis
inactive
Number of active axes that are programmed in the
active datum table
Position programmed
immediately after TOOL CALL, 70
1 - Position valid / invalid (0/0)
2 1 X axis
Group name, ID no. Number Index Meaning
