320 Programming: Q Parameters
9.8 Additional Functions
2 2 Y axis
2 3 Z axis
3 - Programmed feed rate (–1: no feed rate programmed)
Active tool compensation, 200 1 - Tool radius (including delta values)
2 - Tool length (including delta values)
Active transformations, 210 1 - Basic rotation in MANUAL OPERATION mode
2 - Programmed rotation with Cycle 10
3 - Active mirror axis
0: mirroring not active
+1: X axis mirrored
+2: Y axis mirrored
+4: Z axis mirrored
+64: U axis mirrored
+128: V axis mirrored
+256: W axis mirrored
Combinations = sum of individual axes
4 1 Active scaling factor in X axis
4 2 Active scaling factor in Y axis
4 3 Active scaling factor in Z axis
4 7 Active scaling factor in U axis
4 8 Active scaling factor in V axis
4 9 Active scaling factor in W axis
5 1 3-D ROT A axis
5 2 3-D ROT B axis
5 3 3-D ROT C axis
6 - Tilted working plane active / inactive (value not equal to
0/0) in a Program Run operating mode
7 - Tilted working plane active / inactive (value not equal to
0/0) in a Manual operating mode
Path tolerance, 214 8 - Tolerance programmed with cycle 32 or MP 1096
Group name, ID no. Number Index Meaning
