672 Tables and Overviews
18.1 General User Parameters
Reset status display,
Q parameters, tool
data and machining
time
MP7300
Reset all when a program is selected: 0
Reset all when a program is selected and with M2, M30, END PGM: 1
Reset only status display and tool data when a program is selected: 2
Reset only status display, machining time and tool data when a program is selected and with M2,
M30, END PGM: 3
Reset status display, machining time and Q parameters when a program is selected: 4
Reset status display, machining time, and Q parameters when a program is selected and with
M2, M30, END PGM: 5
Reset status display and machining time when a program is selected: 6
Reset status display and machining time when a program is selected and with M2, M30, END
PGM: 7
Graphic display mode MP7310
Projection in three planes according to ISO 128, projection method 1: Bit 0 = 0
Projection in three planes according to ISO 128, projection method 2: Bit 0 = 1
Display new BLK FORM in Cycle 7 DATUM SHIFT referenced to the old datum: Bit 2 = 0
Display new BLK FORM in Cycle 7 DATUM SHIFT referenced to the new datum: Bit 2 = 1
Do not show cursor position during projection in three planes: Bit 4 = 0
Show cursor position during projection in three planes: Bit 4 = 1
Software functions of the new 3-D graphics active: Bit 5 = 0
Software functions of the new 3-D graphics not active: Bit 5 = 1
Limitation of a tool’s
tooth length to be
simulated. Only
effective if LCUTS is
not defined.
MP7312
0 to 99 999.9999 [mm]
Factor by which the tool diameter is multiplied in order to increase the simulation speed. If 0 is
entered, the TNC assumes an infinitely long tooth length, which significantly increases the time
required for the simulation.
Graphic simulation
without programmed
tool axis: Tool radius
MP7315
0 to 99 999.9999 [mm]
Graphic simulation
without programmed
tool axis: Penetration
depth
MP7316
0 to 99 999.9999 [mm]
Graphic simulation
without programmed
tool axis: M function
for start
MP7317.0
0 to 88 (0: Function inactive)
Graphic simulation
without programmed
tool axis: M function
for end
MP7317.1
0 to 88 (0: Function inactive)
Screen saver MP7392.0
0 to 99 [min]
Time in minutes until the screen saver switches on (0: Function not active)
MP7392.1
No screen saver is active: 0
Standard screensaver of the X server: 1
3-D line pattern: 2
TNC displays, TNC editor
