HEIDENHAIN iTNC 530 673
18.1 General User Parameters
Machining and program run
Effect of Cycle 11 SCALING FACTOR MP7410
SCALING FACTOR effective in 3 axes: 0
SCALING FACTOR effective in the working plane only: 1
Manage tool data/calibration data MP7411
The TNC saves the calibrated data for the 3-D touch probe internally: +0
The TNC uses the compensation values for the touch probe from the tool
table as calibration data for the 3-D touch probe: +1
SL cycles MP7420
The following applies to Cycles 21, 22, 23, 24:
Mill channel around the contour—clockwise for islands and
counterclockwise for pockets: Bit 0 = 0
Mill channel around the contour—clockwise for pockets and
counterclockwise for islands: Bit 0 = 1
First mill the channel, then rough out the contour: Bit 1 = 0
Rough out the contour, then mill the channel: Bit 1 = 1
Combine compensated contours: Bit 2 = 0
Combine uncompensated contours: Bit 2 = 1
Rough out to each pocket depth: Bit 3 = 0
Mill pocket and rough-out for each infeed depth before continuing to the
next depth: Bit 3 = 1
The following applies to Cycles 6, 15, 16, 21, 22, 23, and 24:
At the end of the cycle, move the tool to the position that was last
programmed before the cycle call: Bit 4 = 0
At the end of the cycle, retract the tool in the spindle axis only: Bit 4 = 1
Cycle 4 POCKET MILLING and
Cycle 5 CIRCULAR POCKET MILLING:
Overlap factor
MP7430
0.1 to 1.414
Permissible deviation of circle radius
between circle end point and circle starting
point
MP7431
0.0001 to 0.016 [mm]
Limit switch tolerance for M140 and M150 MP7432
Function inactive: 0
Tolerance for the distance by which the software limit switch may be
exceeded with M140/M150: 0.0001 to 1.0000
