HDP5000 High Definition Card Printer/Encoder User Guide L000950 Rev 1.8
13
Reviewing the HDP5000 Sequence of Operations
Step Process
22 The Film Drive and Stepper turn ON for a given number of clicks based on Film
Encoder, until the film is released.
23 The Stepper turns ON to move the card into Flipper Module to flip the card to
the opposite side. After flipping the card is transported back to the Card
Feed/Position Sensor to repeat Steps 9 to 14.
Upon completion of print all print cycles the card is transported to the Output
Hopper (based on steps from a known from Flipper Card Position Sensor). All
stop.
24 The Heater is maintained at a set temperature by the RTD when the Printer is
ON. The cooling fan is ON when the Printhead is ON or hot.

HID HDP5000 Specifications

General

Print Resolution	300 dpi
Interface	USB
Print Technology	Dye sublimation
Card Capacity	100-card input hopper
Connectivity	USB 2.0
Print Capability	Single-sided
Operating System Support	Windows 7, 8, 10
Card Sizes	CR80 (standard credit card size)
