Base Module—P/N 63951S (Sheet 2 of 2) (P3700A)
Chapter 5: Parts List
Affinity® Three Birthing Bed and Affinity® Four Birthing Bed Page 5 - 15
Service Manual (MAN272 REV 4)
5
Table 5-4. Base Module—P/N 63951S (Sheet 2 of 2) (P3700A)
Item Number Part Number Quantity Description
1 60133 12 Hex rivnut
2 61653PL 1 Clevis pin
3 6314308PL 1 Clevis pin
4 63920 1 Hilow/Foot drive
5 61615 4 Rue ring cotter
6 9026304 4 Bearing, DU
7 6392648 1 Intermediate frame weldment
8 66039 4 Nut, jam
9 41022 8 Pivot block
10 43772 As required Lithium base grease
11 6722348 1 Lift arm crank weldment
12 62228 8 Screw, hex hd
13 6722448 1 Lift arm follower weldment
14 41024 4 Pivot block plate
15 27509 4 Roll pin
16 6314304PL 2 Clevis pin
17 6396248 1 Link, hilow lift arms
18 65987 2 Guard, lift arm
19 393 4 Screw, pan hd
20 68189 4 Retaining strap
21 127368 8 Screw with lock patch
