Main Frame Module
Chapter 5: Parts List
Affinity® Three Birthing Bed and Affinity® Four Birthing Bed Page 5 - 17
Service Manual (MAN272 REV 4)
5
Table 5-5. Main Frame Module
Item Number Part Number Quantity Description
1 6391648 1 Cover, top motor
2 41250 1 Headboard bushing, oval
3 43878 17 Screw, button hd Torx®
4 41078 1 Headboard bushing, round
5 41243S48 1 Roller bumper and bracket assembly
6 25208 2 Axle
7 90016-06 4 Cap screw, hex hd
8 3455748 2 Roller bumper
9 25210 4 Pushnut
10 41243 2 Bracket, roller bumper
11 3517 2 Roll pin
12 38135 2 Knob assembly
13 6391948 1 Mainframe weldment
14 61615 4 Rue ring cotter, 3/8"
15 61653PL 3 Clevis pin
16 6314306PL 1 Clevis pin
17 63927 1 Head drive
18 63920 1 Hilow/Foot drive
19 6591548 1 Foot drive extension tube weldment
20 6161501 7 Rue ring cotter
21 6398848 1 Bottom cover weldment
22 41273 1 Seat side shroud, lh
23 393H 4 Screw, pan hd
24 6393348 1 Foot section pivot weldment
25 41023 4 Pivot block, trend
26 48868 2 Clevis pin
27 18921 1 Screw, pan hd truss
28 37879 1 Ground strap assembly
29 13206 1 Screw, pan hd truss
