Main Frame Module
Chapter 5: Parts List
Page 5 - 18 Affinity® Three Birthing Bed and Affinity® Four Birthing Bed
Service Manual (MAN272 REV 4)
Item Number Part Number Quantity Description
30 4886801
or
90260-48
1 Clevis pin (used starting Jan. 2001)
or
Shoulder screw, hex socket hd,
(used prior to Jan. 2001)
31 41263 1 Foot section link bar weldment
32 41413 1 Shroud, front
33 46772-48 1 Placenta basin
34 41111S 1 Yoke casting assembly
35 48868
or
90260-28
4 Clevis pin (used starting Jan. 2001)
or
Shoulder screw, hex socket hd,
(used prior to Jan. 2001)
36 9026301 20 Bushing, DU
37 4887448 3 Foot section lift arm
38 41272 1 Seat side shroud, rh
39 19678 4 Truarc ring
40 36826 2 Ring, retaining
41 9026307 4 Bearing, DU self-lube
42 43039 2 Link, seat pivot
43 41089PL 4 Pin, foot section
44 27509 4 Roll pin
45 41036 4 Bushing, foot section pivot
46 41037PL 4 Plate, foot section bushing
47 9016128 8 Cap screw, hex socket hd
48 20605 4 Locknut
49 41253 1 Bracket, Trendelenburg limit switch
50 34401 2 Spacer
51 19512 2 Switch, snap, spdt
52 31642 4 Screw
53 41450 2 Trendelenburg gas spring
54 9685 2 Roll pin
55 41252 2 Trendelenburg gas head
56 41091 2 Trendelenburg release lever
57 43056 2 Spring, extension
58 43049 2 Screw, shoulder, pan hd cross
