Main Frame Module
Chapter 5: Parts List
Affinity® Three Birthing Bed and Affinity® Four Birthing Bed Page 5 - 19
Service Manual (MAN272 REV 4)
5
Item Number Part Number Quantity Description
59 40497 2 Nut, keps
60 831 2 Locknut
61 9006116 2 Screw
62 41073PL 4 Trendelenburg activator
63 41087PL 2 Trendelenburg follower
64 41135PL 2 Trendelenburg cam
65 41079PL 2 Trendelenburg stop
66 20802 2 Nut, keps
67 4540 2 Washer
68 9025910 2 Shoulder screw, hex socket hd,
5/16-18 x 5/8"
69 SA4840 As required Red Loctite® #271
70 9025916 2 Screw, shoulder, hex socket hd
71 43041 2 Trendelenburg limit spacer
72 15463 2 Bolt
73 40915PL 1 Trendelenburg handle hex bar
74 4630 2 Oilite® bushing
75 4089648 2 Trendelenburg handle assembly
76 4115363 2 Cover, Trendelenburg handle
77 3517 2 Spiral pin, 3/16" x 1¼"
78 4257363 2 Trendelenburg handle foam
79 4116363 2 Trendelenburg handle plug
80 65914 2 Spacer
