Siderail Module
Chapter 5: Parts List
Affinity® Three Birthing Bed and Affinity® Four Birthing Bed Page 5 - 21
Service Manual (MAN272 REV 4)
5
Table 5-6. Siderail Module)
Item Number Part Number Quantity Description
1 62625 4 Screw, pan hd, self-locking
2 4214101 24 Screw, pan hd Torx® hi-lo
3 6860002 1 Siderail cover, patient, rh
4 472730448 16 Screw, nylon
5 6503802 1 P.C. board assembly, caregiver siderail
control, rh
6 6401301 2 Cable assembly, siderail jumper, 11
7 6401302 2 Cable assembly, siderail jumper, 12
8 6528602 1 P.C. board assembly, patient siderail
control, rh
9 4727110PL 4 D-pin
10 35325 18 E-ring
11 42142 6 Screw, pan hd Torx® hi-lo
12 49192PL 4 Pin, latch pivot
13 20802 4 Nut, keps
14 47323 2 Dampener
15 44408 4 Screw, hex washer hd
16 63250 2 Cover, center arm
17 4727102PL 4 D-pin
18 6887248 2 Siderail mounting bracket weldment
(Replaces 4725948 siderail mounting
bracket weldment. When replacing a
4725948 weldment with a 6887248
weldment, also replace 49192PL latch
pivot pin with 68861PL latch pivot
D-pin, and two 35325 E-rings with two
18890 E-rings)
19 47257PL 2 Latch, siderail
20 49111 2 Spring, latch bias
21 19124 2 Cable tie
22 62753 2 Center arm, siderail
Item Number Part Number Quantity Description
23 47144PL 2 Shaft, pivot, siderail release lever
