Siderail Module
Chapter 5: Parts List
Page 5 - 22 Affinity® Three Birthing Bed and Affinity® Four Birthing Bed
Service Manual (MAN272 REV 4)
24 3005804 2 Cable assembly, audio taper
25 6397501 2 Siderail arm, lh
26 63977 2 Upper rail
27 47256 2 Lever, siderail release
28 6397648 2 Siderail center weldment
29 67060 2 Seal, siderail
30 4096301 2 Knob, volume
31 6528601 1 P.C. board assembly, patient siderail
control, lh
32 6397901 1 Siderail cover, patient, lh
33 6397502 2 Siderail arm, rh
34 38873 2 Speaker
35 28562 8 Palnut
36 6860001 2 Siderail cover, caregiver
37 6503801 1 P.C. board assembly, caregiver siderail
control, lh
38 63969 4 Bushing
39 66861 4 Hex gasket, top cane
40 60619 8 Nut, nylock
41 9001656 8 Cap screw, hex hd
42 64011 2 Cable assembly, siderail
43 49193 2 E-ring
44 66860 2 Gasket, top cane
45 4565820 2 Ground strap, 20" (51 cm)
46 43878 2 Screw, button hd Torx®
47 68537 2 Plug, volume control
Item Number Part Number Quantity Description
