Sleep Deck Module (Sheet 3 of 3)
Chapter 5: Parts List
Affinity® Three Birthing Bed and Affinity® Four Birthing Bed Page 5 - 41
Service Manual (MAN272 REV 4)
5
Table 5-14. Sleep Deck Module (Sheet 3 of 3)
Item Number Part Number Quantity Description
1 42575 1 Wireform, V seat
2 42576 1 Wireform, U seat
3 1012 2 Washer
4 9001828 2 Cap screw, hex hd
5 6724448
or
448170148
1 Foot section weldment, lift-off (used
with 67415 yoke spacer and 4257401 cap
screw only)
or
Foot section weldment, lift-off (used
with 42574 cap screw only)
6 9001828 4 Cap screw, hex hd
7 1012 8 Washer
8 41204S 1 Latch weldment, lh
9 4435 4 Locknut
10 4257401
or
42574
6 Cap screw, hex socket flat hd (used with
6724448 foot section weldment and
67415 yoke spacer only)
or
Cap screw, hex socket flat hd (used with
448170148 foot section weldment only)
11 61510 1 Latch, foot, lh
12 67415 2 Spacer, yoke (used with 6724448 foot
section weldment and 4257401 cap
screw only)
13 41104 2 Bumper, foot section
14 90058-06 4 Screw, truss hd cross, patchlock
15 44768 4 Screw, flat hd machine
16 41052 4 Stud snap
17 15250 4 Locknut, washer-base
18 46765 2 Hole plug
19 61509 1 Latch, foot, rh
20 41203 1 Latch weldment, rh
21 615140148 1 Foot section weldment, slide-off
