Sleep Deck Module (Sheet 3 of 3)
Chapter 5: Parts List
Page 5 - 42 Affinity® Three Birthing Bed and Affinity® Four Birthing Bed
Service Manual (MAN272 REV 4)
Item Number Part Number Quantity Description
22 9023428 4 Locknut
23 6356601PL 1 Bracket weldment, lh
24 63611 4 Screw, hex socket flat hd
25 18890 2 Truarc ring
26 61532PL 2 Pivot stud
27 61534 1 Spring, non-corrosive torsion
28 63565 1 Pivot shaft
29 61525 2 Bearing
30 35326 4 E-ring
31 6153401 1 Spring, torsion, lh
32 61537 1 Bracket, slide, lh
33 42574 6 Screw
34 6341601PL 1 Latch weldment, lh
35 61529PL 2 Connecting rod
36 6153002PL 1 Release handle, lh
37 6153001PL 1 Release handle, rh
38 61533 2 Vinyl cap
39 61531PL 4 Link rivet
40 6341602PL 1 Latch weldment, rh
41 61536 1 Bracket, slide, rh
42 46765 4 Hole plug
43 6356602PL 1 Bracket weldment, rh
44 (not
shown)
6781702S 1 Foot section, Lift-off, complete—
straight cut
6781701S 1 Foot section, Lift-off, complete—U cut
45 (not
shown)
6781704S Foot section, slide-off, complete—
straight cut
6781703S Foot section, slide-off, complete—U cut
