Foot Support Module—P3700A
Chapter 5: Parts List
Affinity® Three Birthing Bed and Affinity® Four Birthing Bed Page 5 - 51
Service Manual (MAN272 REV 4)
5
Table 5-19. Foot Support Module—P3700A
Item Number Part Number Quantity Description
1 6563703 1 Foot support module with calf support,
lh
2 6563701S 1 Foot support module, lh
3 6697001S 1 Calf support module, lh
4 65700 4 Oilite® bushing
5 6572401PL 1 Cam post weldment, lh
6 66966 2 Set screw, cup point
7 19124 2 Cable tie
8 6580101 1 Mechlok®, lh
9 35325 4 E-ring
10 65799 2 Cable, foot abduction
11 6604202 4 Clevis pin
12 61615 4 Rue ring cotter
13 65829 2 Toe boot
14 62919 2 Cap, release handle, vinyl dipped
15 39172 As required Adhesive
16 65699PL 2 Release handle weldment
17 67686 8 Plug
18 64466 8 Screw, Torx®
19 62959 2 Handle/bumper, foot support
20 6604101 1 Heel cup, foot support, lh
21 67794 2 Wireform, bellows
22 9025806 1 Screw, shoulder
23 65800 2 Cable, foot tilt
24 66152 2 Gas spring, foot support
25 6696501 1 Mechlok®, foot tilt, lh
26 656320148 1 Foot rest weldment, lh
27 6582801 1 Bellows, foot support, lh
