Foot Support Module—P3700A
Chapter 5: Parts List
Page 5 - 52 Affinity® Three Birthing Bed and Affinity® Four Birthing Bed
Service Manual (MAN272 REV 4)
Item Number Part Number Quantity Description
28 66430 2 Washer, plastic
29 65964 2 Snap ring
30 6580102 1 Mechlok®, rh
31 6572402PL 1 Cam post weldment, rh
32 6604102 1 Heel cup, foot support, rh
33 6696502 1 Mechlok®, foot tilt, rh
34 656320248 1 Foot rest weldment, rh
35 6582802 1 Bellows, foot support, rh
36 6563704 1 Foot support module with calf support,
rh
37 6563702S 1 Foot support module, rh
38 6697002S 1 Calf support module, rh
39 68112 2 Foot support post plug
