Main Frame Module—P3700D
Chapter 5: Parts List
Affinity® Three Birthing Bed and Affinity® Four Birthing Bed Page 5 - 105
Service Manual (MAN272 REV 4)
5
Table 5-38. Main Frame Module—P3700D
Item Number Part Number Quantity Description
1 67048 1 Shroud
2 9023404 2 Nut
3 41413 1 Front shroud
4 41153 2 Trend handle cover
5 4677248 1 Placenta basin
6 41091 2 Trend release lever
7 4540 2 Steel washer
8 40896 2 Trend handle weldment
9 47219 2 Bumper
10 4630 2 Oilite® bushing
11 4715301 2 Bumper pin
12 163860 2 Bushing
13 43878 4 Screw
14 41073 4 Trend activator
15 41087 2 Trend follower
16 41135 2 Trend cam
17 3517 2 Roll pin
18 40915 1 Trend handle hex bar
19 42573 2 Trend handle foam
20 60619 2 Nut
21 41163 2 Trend handle plug
22 27509 4 Roll pin
23 41023 4 Trend pivot block
24 33680 2 Nut
25 41036 4 Bushing
26 63920 1 Drive, hi-lo, foot
27 65915 1 Extension tube, foot drive
28 63933 1 Foot section pivot weldment
29 63927 1 Drive, head
30 393 4 Screw
31 41273 1 Shroud, seat side, lh
32 71993 7 Screw
33 43041 2 Limit switch spacer
