Main Frame Module—P3700D
Chapter 5: Parts List
Page 5 - 106 Affinity® Three Birthing Bed and Affinity® Four Birthing Bed
Service Manual (MAN272 REV 4)
34 41272 1 Shroud, seat side, rh
35 48874 4 Foot section lift arm
36 41252 2 Trend gas head
37 41079 2 Trend stop
38 41253 1 Trend limit switch bracket
39 43059 2 Retaining ring
40 34401 2 Spacer
41 9026301 20 Self lubricating bearing
42 41263 1 Foot section link bar
43 142320 2 Trend gas spring
44 19512 2 Limit switch
45 20605 4 Locknut
46 41112 1 Yoke casting
47 34402 4 Screw
48 65967 4 Clevis pin
49 41089 4 Foot section pin
50 165540 2 Screw
51 9685 2 Roll pin
52 4886801 1 Clevis pin
53 9025916 2 Shoulder bolt
54 36826 2 Retaining ring
55 10595 2 Screw
56 9025910 2 Shoulder bolt
57 19678 4 Truarc ring
58 48868 2 Clevis pin
59 63916 1 Top cover
60 41078 1 Headboard bushing, round
61 41250 1 Headboard bushing, oval
62 61653 3 Pin, clevis
63 43056 2 Extension spring
64 9006116 2 Screw
65 61615 4 Rue ring
66 6161501 7 Rue ring
67 15463 2 Bolt
Item Number Part Number Quantity Description
