2.8 Foot Up Malfunction
Chapter 2: Troubleshooting Procedures
Affinity® Three Birthing Bed and Affinity® Four Birthing Bed Page 2 - 23
Service Manual (MAN272 REV 4)
2
7. Set your VOM to measure V DC. At the logic control P.C. board connector
P6, place your black probe into pin 1 (black wire) and your red probe into
pin 2 (blue wire). Press the foot up switch. The voltage is between 25V DC
and 30V DC.
Yes No
Replace the logic control P.C. board (refer to procedure 4.23).
If this solves the problem, go to “Final Actions” on page 2-10.
Otherwise, continue to step 8.
8. Replace the foot motor (refer to procedure 4.6).
This solves the problem.
Yes No
Contact Hill-Rom Technical Support.
9. Go to “Final Actions” on page 2-10.
