4.6 Foot Drive Motor Assembly
Chapter 4: Removal, Replacement, and Adjustment Procedures
Affinity® Three Birthing Bed and Affinity® Four Birthing Bed Page 4 - 21
Service Manual (MAN272 REV 4)
4
15. Remove the foot drive motor assembly (C).
Replacement
1. To install the replacement foot drive motor assembly (C), reverse the
removal procedure.
2. Do the “Function Checks” on page 2-4.
