3.4 Viewing Harmonic Measured Values
73
Total harmonic voltage distortion (THD V %), total harmonic current distortion (THD A %)
Fundamental wave voltage RMS value (FND V), fundamental wave current RMS value (FND A),
fundamental wave active power (FND W), fundamental wave apparent power (FND VA),
fundamental wave reactive power (FND var), fundamental wave power factor (FND PF),
fundamental voltage/current phase difference (FND °)
Parameters shown with normal display parameters
Example: THD V%
Press or to display THD V % or
THD A % in the display area.
Parameters shown as fundamental wave parameters (displayed as RECTIFIER FND)
Measurement parameters displayed using harmonic analysis (harmonic level, content percentage, rectifier
FND [fundamental wave component]) are not averaged by the averaging function.
1 Press to place the instrument
in the shift state.
2 Press through to display
FND.
(Press through to change the dis-
play parameter.)
Example: FND V
1
