1-128
OPERATOR'S STATION
Vehicle Icon
The vehicle icon is a bird’s eye view of the vehicle from
directly above it.
The vehicle icon on the monitor makes it possible to
imagine the orientation of the vehicle and the position of
the cab.
Cab
vehicle
123
MDCK-OP3-017
Front
Rear
Cab
Rear
Vehicle Boundary Line Vehicle Boundary Line
Vehicle Boundary Line
Front
MDC1-01-578
