mirror
OVERVIEW
Category:
configPrimary context:
Related Commands
Usage: 1) mirror <1-4> [ name NAME-STR ] port PORT-NUM
2) mirror <1-4> [ name NAME-STR ] remote ip SRC-IP-ADDR
SRC-UDP-PORT DST-IP-ADDR
3) mirror <1-4> [ name NAME-STR ] remote ip SRC-IP-ADDR
SRC-UDP-PORT DST-IP-ADDR
4) no mirror <1-4> [ name NAME-STR ]
5) mirror endpoint ip SRC-IP-ADDR SRC-UDP-PORT DST-IP-ADDR
port PORT-NUM
6) no mirror endpoint ip SRC-IP-ADDR SRC-UDP-PORT DST-IP-ADDR
Description: Dene the mirror destinations for diagnostic purposes. The device
ports or VLANs that will be monitored are dened through
the 'monitor' command in either interface or VLAN context.
The network trafc seen by the monitored ports/VLANs is copied to
the mirror destination to which a network analyzer can be attached.
When mirroring multiple ports/VLANs in a busy network,
some frames may not be copied to the monitoring destination.
Parameters: o <1-4> - Mirror destination number
o name NAME-STR - Friendly name to be associated with the
mirror destionation number.
o PORT-NUM - Port that will be acting as the monitoring port. It
cannot be a trunked port. The parameter must be specied,
if the 'no' keyword is not used. Otherwise, it must not be
present.
o SRC-IP-ADDR - source ip address for remote mirroring.
o SRC-UDP-PORT - source UDP port for remote mirroring.
o DST-IP-ADDR - destination ip address for remote mirroring.
Note1: The SRC-IP-ADDR, SRC-UDP-PORT, and DST-IP-ADDR specied on the
source switch must match those on the respective destination switch.
Note2: The SRC-IP-ADDR, SRC-UDP-PORT, and DST-IP-ADDR must not be uses if the
'no' keyword is used unless the 'endpoint' keyword is used.
COMMAND STRUCTURE
■ [no] mirror endpoint -- Remote mirroring destination configuration. (p. 378)
■ ip -- Remote mirroring destination configuration. (IP-ADDR) (p. 378)
■ mirror_session_ip_udp < 1 to 65535 > -- Remote mirroring UDP encapsulation port.
(TCP/UDP-PORT) (p. 379)
■ mirror_session_dest_ip -- Remote mirroring UDP encapsulation destination ip addr.
(IP-ADDR) (p. 379)
■ port -- Remote mirroring destination port. ([ethernet] PORT-NUM) (p. 380)
■ [no] mirror mirror_session_id < 1 to 4 > -- Mirror destination number. (p. 379)
■ name -- Mirroring destination name string. (ASCII-STR) (p. 380)
■ port -- Mirroring destination monitoring port. ([ethernet] PORT-NUM) (p. 380)
■ remote -- Remote mirroring destination configuration. (p. 380)
377© 2009 Hewlett-Packard Development Company, L.P.
