■ well-defined < af11 | af12 | af13 | ... > -- Define Differentiated Services Codepoint to
which to map IP ToS. (p. 434)
■ integer-codepoint < 0 to 63 > -- Specify the DSCP code-point in decimal. (p. 422)
■ dscp -- Define Differentiated Services Codepoint to which to map IP ToS. (p. 418)
■ binary-range < 0 to 63 > -- Specify the DSCP code-point in binary. (BINARY) (p. 416)
■ integer-range < 0 to 63 > -- Specify the DSCP code-point in decimal. (p. 423)
■ well-defined < af11 | af12 | af13 | ... > -- Define Differentiated Services Codepoint to
which to map IP ToS. (p. 434)
■ well-defined-codepoint < af11 | af12 | af13 | ... > -- Configure the Type-of-Service method
the device uses to prioritize IP traffic (p. 453)
■ dscp -- Define Differentiated Services Codepoint to which to map IP ToS. (p. 418)
■ binary-range < 0 to 63 > -- Specify the DSCP code-point in binary. (BINARY) (p. 416)
■ integer-range < 0 to 63 > -- Specify the DSCP code-point in decimal. (p. 423)
■ well-defined < af11 | af12 | af13 | ... > -- Define Differentiated Services Codepoint to
which to map IP ToS. (p. 434)
■ ip-precedence -- In IP-Precedence mode, IPv4 packets are classified and given a QoS priority
based on the upper 3 bits of the IP ToS field. The priority association is automatic and cannot
be changed: IP-Precedence 802.1p ToS Bits Priority -------------------------------- 111 7 (Highest) 110
6 101 5 100 4 011 3 010 0 (Normal) 001 2 (Low) 000 1 (Lowest) (p. 424)
EXAMPLES
Example: qos
The following example shows the 802.1p priority for the UDP and TCP port prioritization.
ProCurve(cong)# qos tcp-port 23 priority 7
ProCurve(cong)# qos udp-port 23 priority 7
ProCurve(cong)# qos tcp-port 80 priority 2
ProCurve(cong)# qos udp-port 80 priority 1
ProCurve(cong)# qos udp-port range 100 199 priority 3
ProCurve(cong)# show qos tcp-udp-port-priority
TCP/UDP port based priorities
| Application |
Protocol | Port Apply rule | DSCP Priority
-------- + ----------- ---------- + ------ -----------
TCP | 23 Priority | 7
UDP | 23 Priority | 7
TCP | 80 Priority | 2
UDP | 80 Priority | 1
UDP | 100-199 Priority | 3
Example: qos
This example assigns the DSCP policies to the selected UDP/TCP port applications.
ProCurve(cong)# qos udp-port 23 dscp 000111
ProCurve(cong)# qos tcp-port 80 dscp 000101
ProCurve(cong)# qos tcp-port 914 dscp 000010
ProCurve(cong)# qos udp-port range 1001 2000 dscp 000010
ProCurve(cong)# show qos tcp-udp-port-priority
TCP/UDP port based priorities
414© 2009 Hewlett-Packard Development Company, L.P.
qosCommand Line Interface Reference Guide
