<Sysname> display nqa reaction counters admin test
NQA entry (admin admin, tag test) reaction counters:
Index Checked Element Threshold Type Checked Num Over-threshold Num
1 probe-duration accumulate 12 4
2 probe-duration average - -
3 probe-duration consecutive 160 56
4 probe-fail accumulate 12 0
5 probe-fail consecutive 162 2
Table 7 Command output
Field
Description
Index ID of a reaction entry.
Checked Element Monitored performance metric.
Threshold Type Threshold type.
Checked Num
Number of targets that have
been monitored for data
collection.
Over-threshold Num Number of threshold violations.
Table 8 Description of the threshold monitoring fields
Monitored
performance
metric
Threshold
type
Collect data in Checked Num Over-threshold Num
probe-duration
accumulate
P
robes after the
operation starts.
N
umber of
completed probes.
Number of probes with
duration exceeding the
threshold.
average N/A N/A N/A
consecutive
P
robes after the
operation starts.
N
umber of
completed probes.
Number of probes with
duration exceeding the
threshold.
probe-fail
accumulate
P
robes after the
operation starts.
N
umber of
completed probes.
Number of probe failures.
consecutive
P
robes after the
operation starts.
N
umber of
completed probes.
Number of probe failures.
RTT
accumulate
P
ackets sent
after the
operation starts.
Number of sent
packets.
Number of packets with
round-trip time exceeding
threshold.
average N/A N/A N/A
jitter-DS/jitter-SD
accumulate
P
ackets sent
after the
operation starts.
Number of sent
packets.
Number of packets with
the one-
way jitter
exceeding the threshold.
average N/A N/A N/A
OWD-DS/OWD-SD N/A
P
ackets sent
after the
operation starts.
Number of sent
packets.
Number of packets with
the one-
way delay
exceeding the threshold.
packet-loss accumulate
P
ackets sent
after the
operation starts.
Number of sent
packets.
Total packet loss.
