HPE FlexNetwork MSR3012 User Manual

370
Field
Description
Type DstIP(Port) SrcIP
(Port)
Pro ToS VNI APPID If(Direct) Pkts
Statistics of the active flows in the current cache:
• Flow type. Flows are classified into the following types:
 Layer 3 flows.
 Layer 2 flows.
 Layer 2 and Layer 3 flows.
 MPLS flows without IP options.
 MPLS flows with IP options.
• Destination IP address (destination port).
• Source IP address (source port).
• Protocol number.
• ToS.
• Application layer protocol ID.
• Interface name (direction).
• Number of packets.
ICMP packets do not contain port number fields, so the type and
code fields are captured. The value for the destination port
represents these two fields:
• The highest 8 bits represent the type field.
• The lowest 8 bits represent the code field.
The value for the source port is set to 0 and does not indicate any
statistics.
DstMAC(VLAN) SrcMAC(VLAN)
Layer 2 information of the active flows in the current cache:
• Destination MAC address.
• Destination VLAN ID.
• Source MAC address.
• Source VLAN ID.
TopLblType(IP/Mask)
Lbl-Exp-S-List
Information about the active MPLS flows in the current cache:
• Type of the labels at the top of the label stack:
 IP address associated with the label.
 Mask associated with the label.
• Label list.
Up to three labels can be listed in one label list.
