4. Disconnect all peripheral cables from the server.
5. Remove the server from the rack.
6. Place the server on a flat, level surface.
7. To remove the sliding rails, do the following:
a. Pull and hold the release latch (callout 1).
b. Slide the rail towards the front panel and pull it from the server (callout 2).
c. Repeat steps a and b to remove the other rail.
8. To remove the rack mounting rails, do the following:
a. In a threaded-hole rack, remove the rail screws.
b. Disengage the rail pins from the rack columns (callouts 1 and 2).
