Serial port cablingSerial port cabling

Cable part numberCable part number ColorColor FromFrom ToTo

873747-001 Orange Serial port Serial port connector

Option kit: P59431-B21

Optical drive cablingOptical drive cabling

Optical drive cabling in the SFF chassisOptical drive cabling in the SFF chassis

HPE ProLiant DL385 Gen11 Server Maintenance and Service Guide 357
