HPE ProLiant DL385 Gen11 - Tertiary riser components; GPU riser components

To Next Page

To Previous Page

ItemItem DescriptionDescription

1 Storage controller backup power connectors

2 PCIe5 x16 (16, 8, 4, 1) slots

3 Riser power connectors

Tertiary riser componentsTertiary riser components

ItemItem DescriptionDescription

1 Storage controller backup power connector

2 PCIe5 x16 (16, 8, 4, 1) slots

3 Riser board power connector

4 Power cable

GPU riser componentsGPU riser components

HPE ProLiant DL385 Gen11 Server Maintenance and Service Guide 289
