3. Remove all power:
a. Disconnect each power cord from the power source.
b. Disconnect each power cord from the server.
4. Disconnect all peripheral cables from the server.
5. Remove the server from the rack .
6. Place the server on a flat, level work surface.
7. Remove the access panel.
8. Do one of the following:
a. Remove the air baffle.
b. Remove the midplane drive cage .
9. Remove the chassis intrusion detection switch:
a. Disconnect the switch cable and release it from the cable clamp (callout 1).
b. While carefully retracting the snap-in latch (callout 2), pull out the tab from the chassis slot (callout 3).
