a. Do one of the following:
Remove the air baffle.
Remove the midplane drive cage .
b. Remove the rear 4 LFF drive cage .
c. Remove the NS204i-u + secondary low-profile riser cage .
10. Remove the boot device security cover:
On the boot device riser cage
On top of the power supply cage
11. Remove the boot device carrier:
a. Press and hold the carrier latch (callout 1).
b. Pivot the latch to open (callouts 2).
