hpmont HD5L-PLUS Series User Manual

Shenzhen Hpmont Technology Co., Ltd. Appendix A Parameters
HD5L-PLUS Series User Manual V1.0 95
Appendix A Parameters
Attributes are changed:
“*”: It denotes that the value of this parameter is the actual value which cannot be modified.
“×”: It denotes that the setting parameter cannot be modified when the controller is in run status.
“
○
”: It denotes that the setting parameter can be modified when the controller is in run status.
Ref. Code
Function Setting Range Default Unit
Attribute
Setting
D00: System Status Parameters (on page 45 - 46)
D00.00 Controller series HD5L-PLUS Actual *
D00.01 Software version of DSP 0.00 - 9.99 Actual *
D00.02
Special software version of
DSP
0.00 - 9.99 Actual *
D00.03 Software version of keypad 0.00 - 9.99 Actual *
D00.04 Elevator running status
Bit0: Controller enable
Bit1: Inspection run
Bit2: MS run
Bit3: Analog run
Bit4 - Bit7: Unused
Bit8: Brake feedback input
Bit9: Contactor feedback input
Bit10: Up forced speed switch
input
Bit11: Down forced speed
switch input
Bit12: MS terminal 1
Bit13: MS terminal 2
Bit14: MS terminal 3
Bit15: Emergency run
Actual *
D00.05 Rated current of HD5L-PLUS 0.1 - 999.9A Actual *
D00.06 Controller status
Bit0: Controller fault
Bit1: Run/stop
Bit2: UP
Bit3: DN
Bit4&5:
Acceleration/Deceleration/Cons
tant
Bit6: Zero-speed signal
Bit7: Zero-speed running
Bit8: Auto-tuning
Bit9: Speed within FAR
Bit10: Ready to run
Bit11: Brake output
Bit12: Contactor output
Bit13: Stop signal
Bit14, Bit15: Unused
Actual *
A
