Appendix A Parameters Shenzhen Hpmont Technology Co., Ltd.
96 HD5L-PLUS Series User Manual V1.0
Ref. Code
Function
Setting Range Default
Unit
Attribute
Setting
D01: Drive Status Parameters (on page 46 - 46)
D01.00 Control mode 0 - 5 Actual *
D01.01 Setting speed (m/s) 0.000 - 9.999 Actual *
D01.02
Setting speed (after Acc./Dec.)
(m/s)
0.000 - 9.999 Actual *
D01.03 Feedback speed (m/s) 0.000 - 9.999 Actual *
D01.04 Setting frequency (Hz) 0.01 - 100.00Hz Actual *
D01.05
Setting frequency (after
Acc./Dec.)
0.01 - 100.00Hz Actual *
D01.06 Output frequency 0.01 - 100.00Hz Actual *
D01.07 Setting Rpm 0 - 24000rpm Actual *
D01.08 Running Rpm 0 - 24000rpm Actual *
D01.10 Output voltage 0 - 999V Actual *
D01.11 Output current 0.1 - 999.9A Actual *
D01.12 Output torque
0.0 - 300.0% (motor rated
torque)
Actual *
D01.13 Output power
0.0 - 200.0% (motor rated
power)
Actual *
D01.14 DC bus voltage 0 - 999V Actual *
D02: Analog Status Display Parameters (on page 46 - 46)
D02.00 AI1 voltage 0.00 - 10.00V Actual *
D02.01 AI1 voltage (after calculating) 0.00 - 10.00V Actual *
D03: Running Status Parameters (on page 46 - 47)
D03.00 Heatsink temperature 0.0 - 999.9°C Actual *
D03.01 Input terminal status
Bit9 - Bit0 correspond to DI12 -
DI1
Bit15 - Bit11: Unused
0: Disconnects with common
terminals
1: Connects with common
terminals
Actual *
D03.02 Output terminal status
Bit1&Bit0 correspond to
DO2&DO1
Bit4 - Bit2 correspond to Y3 - Y1
Bit5 corresponds to Y4 (RLY )
Bit15 - Bit6: Unused
Actual *
D03.03 Modbus status
0: Normal
1: Communication timeout
2: Incorrect data frame head
3: Incorrect data frame checking
4: Incorrect data frame content
Actual *
