Chapter 7 Elevator Application Guidance Shenzhen Hpmont Technology Co., Ltd.
82 HD5L-PLUS Series User Manual V1.0
Ref. Code Function Value Remark
F05.00 Multi-speed 0 0
Determined by design
F05.01 Multi-speed 1 Re-leveling speed
F05.02 Multi-speed 2 Creeping speed
F05.03 Multi-speed 3 Emergency speed
F05.04 Multi-speed 4 Inspection speed
F05.05 Multi-speed 5 Normal low speed
F05.06 Multi-speed 6 Normal middle speed
F05.07 Multi-speed 7 Normal high speed
F06.00 Pre-torque selection 4 No weighing auto-compensation
F06.14 No weighing current coefficient 3000
Debugging according to the
running effect
• Increase the value when the
motor does not oscillate
F06.15 No weighing speed-loop KP 2000
F06.16 No weighing speed-loop KI 2000
F12.01 DI1 function 1 Controller enabled (EN)
F12.02 DI2 function 2 UP
F12.03 DI3 function 3 DN
F12.04 DI4 function 4 MS1
F12.05 DI5 function 5 MS2
F12.06 DI6 function 6 MS3
F12.15 DO1 function 2 Controller is in running
F12.16 DO2 function 3 Controller is in zero-speed running
F12.20 Y4 (RLY) output function 14 Controller fault
F16.07 Multi-speed inspection 4 Multi-speed inspection select
