Set Parameter
See Table 7-1 for general parameter settings for terminal operation, and see Table 7-2 for special
parameter settings.
Table 7-1 General parameter
Ref. Code Function Value Remark
F00.00 Motor type Depend on actual value
F00.01 Control mode Depend on actual value
F00.02 Rated speed of elevator Depend on actual value
F00.03 The Max. output freqency Depend on actual value
F00.04 Mechanical parameters of motor Depend on actual value
F07.00/F10.01 Rated power of motor Depend on actual value
Motor nameplate
parameters
F07.01/F10.02 Rated voltage of motor Depend on actual value
F07.02/F10.03 Rated current of motor Depend on actual value
F07.03/F10.04 Rated frequency of motor Depend on actual value
F07.04/F10.05 Rated rpm of motor Depend on actual value
F08.00/F08.02 ASR proportional gain 1/2 500
Adjust according to
running effect.
• Generally use the
default value
F08.01/F08.03 ASR integral coefficient 1/2 500
F08.04 ASR swithcing frequency 1 10.00Hz
F08.05 ASR swithcing frequency 2 15.00Hz
F11.00 PG card selection Depend on actual value
F11.01 Encoder pulses per revolution Depend on actual value
F11.02 Encoder rotation direction setting Depend on actual value
Table 7-2 Terminal MS run
Ref. Code Function Value Remark
F00.05 Operating mode 2 Terminal MS control
F02.02 Retention time of start zero-speed 0.5s Adjust according the situation of
running contactor and brake at
motor start&stop
F02.06 Retention time of stop zero-speed 0.5s
F03.00 Acc. speed 0.700m/s
2
Set according the elevator speed
and running effect
F03.01 Start Acc. jerk 0.350m/s
3
F03.02 End Acc. jerk 0.600m/s
3
F03.03 Dec. speed 0.700m/s
2
F03.04 Start Dec. jerk 0.600m/s
3
F03.05 End Dec. jerk 0.350m/s
3
F03.06 Inspection Acc. speed 0.200m/s
2
F03.07 Inspection Dec. speed 1.000m/s
2
F03.13 Stop Dec. jerk 0.350m/s
3
To Next Page
